Dental LED Curing Light & Light Activated Disinfection system utilises Photo-Activated Disinfection to eliminate bacteria in the treatment of root canals, periodontal disease, peri-implantitis and caries by eliminating all species of oral bacteria on demand.
Dental LED Curing Light & Light Activated Disinfection represents a genuine advance in minimal invasive dental treatment. It provides consistent, fast, effective and simple disinfection, with no side effects.
Dental LED Curing Light & Light Activated Disinfection purely dental bule light, solidify all brands of resin materials.

For the practitioner there are four important benefits to using this item:
-Saving time – reduced treatment and single visit treatment possible;
-Saving supporting tissue in periodontal disease without antibiotics;
-Saving expensive implants by total disinfection of the implant site prior to placement and also of the implant and surrounding tissue in case of infection;
-Saving hard tissue with minimally invasive procedures and encouraging the process of natural remineralization;

Unique benefits to the general dentist:
-It kills all bacteria associated with all types of oral lesions
-It saves time and enables endo treatment in a single visit
-It works only at the infection site, reducing the need for other local and systemic antimicrobials
-It compliments minimally invasive treatment as a simple, adjunct to your usual restorative procedure
- It improves and speeds up the healing process
- It is painless and welcomed by patients especially children
-It is safe, with no known side-effects

And significant benefits for patients
* Less time to complete root canal treatment
* Less likelihood of failed root canal treatmen
* Less complex treatment of periodontal pockets
* Less likelihood of implant failure
* Less need for aggressive antimicrobials and systemic antibiotics
* Less invasive cavity prep
* Less risk of pulpal exposure in treating deep decay
* Less risk of losing teeth
* Less trauma for children and dental phobics

Application in Periodontal Therapy

1 Thoroughly debride the site [SRP] using preferred technique.
2 Following control of the bleeding from instrumentation,insert the photosensitiser solution into the pocket ensuring that it penetrates to the base of the pocket. Retain the solution in the pocket for 60 seconds.
3 Attach perio tip to the light guide of the 686HELEN+ handpiece. Insert the perio tip so that it is in contact with the bottom of the pocket. Then activate the light for 60 seconds.
4 Review status after four weeks. The process may be repeated if necessary.
Application in Caries Treatment

1 Isolate from saliva with cotton wool rolls and high speed aspiration or rubber dam. Remove only sufficient enamel to access the carious lesion.
2 With excavator or slow running dental handpiece and round bur, remove only infected tissue. Stop immediately when resistance is felt.
3 Apply Aseptim solution to the whole lesion with brush. Work into surface of infected tissue and cover the whole cavity. Continue for 60 seconds.
4 Place DB686 HELEN+ handpiece tip over the site of the lesion and hold just above the cusps on the occlusal surface of the tooth.
5 Activate red light for 60 seconds and hold the tip centred on the lesion. Light penetrates through the surrounding tissue to activate the Aseptim solution and disinfects the remaining lesion. If two interproximal surfaces are involved,disinfect each surface separately.
6 After disinfection, either; a) fill cavity immediately with suitable restorative or b) before final filling, treat remaining softened tissue with remineralising agent. Note: glass ionomers are particularly appropriate to seal and assist in remineralisation of deep cavities.

Feature

1. Muti-function include LED curing light and Light activated disinfection
2. Automatically identify the blue and red light,blue light for solidify resin material, red light is Caries detector
3. Non-contact recharge design, avoid the poor contact an prevent the liguid from reaching the contact
4. battery is detachable
5. Light source is detachable and 360 degree rotation

Technial

1. Voltage: AC100-240V
Curing Light:Wavelength: 420-480nm
2. Intensity: ≧1200mw/c㎡
Working time: 5S, 10S, 20S
3. Light activated disinfection:
Wavelength: 635nm(±20)
Intensity: 2000-3000mw/c㎡
Working time: 60s, 120s
4. Volume/Weight:
Volume: 19*12.6*8.5CM
Weight: 0.75Kg

Warranty: One Year! Service: Whole Life!
