Feature:
1.Mainly used in Saprodontia ,Root canal ,Periodontal ,Crown and so on dental field,help dentist to diagnose more conveniently and easily
2. New designed intraoral camera can use with our software and save image in it,no need to work with LCD monitor
3.High definition image and good price
4.CE certificate
5.Offer 1 year warranty
Technical：
Sensor: APS CMOS sensor
External dimension (mm) :40×26(AT-301)
Sensor Active Area : 30×22.5(AT-301)
Sensor Thickness : 6mm
Dynamic Range : 0~4,096
Power : 5V±0.5V
Image Transfer :USB2.0
Cable Length :.≥ 3m
Computer System Requirements:
Processor: Intel 1.2GHz chip or above;
Memory: Above 1G ;
Hard disk: Above 40G;
Interface: USB 2.0;
Display: Resolution 1024 × 758 (15") or above
Operating System: Windows XP
The computer connected to system shall be in accordance withIEC 60950-1:6005.
Transport And Storage Conditions:
Environment Temperature: -25℃~+60℃;
Environment relative humidity : 10%~93%;
Air pressure : 860hPa~1060hPa;
Operating Conditions:
Environment Temperature : +10℃～+40℃
Environment relative humidity : ≤95%；
Air pressure : 860hPa～1060hPa；
Safety Classifications:
Safety Type: Class-Ⅱ BF
Power: DC5V Maximum 600MA.Rate of Work: Max 1W
Degree of protection against ingress of water: IPX7
Non AP equipment, non APG equipment
Mode of operation: Continuous operation
Packing List:
Manual 1pc
CD 1pc
X-Ray Sensor with controller 1pc
Holder 1pc
Sleeves 1bag
Warranty: One Year! Service: Whole Life!
