Features:
1. This is a dental High Speed turbine handpiece with 4 holes or 2 holes.
2. Modern clipper-built designation, with elegant and attractive appearance.
3. Durable. fastidiously request for designation, technology and materials.
4. Comfortable handle. slide-proof, comfortable to hold and easy to clean.
5. Burs would be easily changed with the Key lock
6. Offering a better eyeshot and angle, improving your efficiency.
7. High density cartridge, with high cutting efficiency but less vibration and noise.
8. Autoclavable. Suitable for disinfection of high-temperature steam at 135 , conform to modern clinical requirement.
9. Shoule be professionally used by dentists to diagnose, cure and operate on patients'teeth.
10.It is only for people who have dentistry medical qualification:
Chucking power of chucking needle is 20N-45N.
11.It is noise-free and stable.
12.Applicable Bur: 1.6mm and should be conformed to ISO standard.
13.Idling speed of handpiece should be no less than 370,000 rotations under working air pressure of 25-30 pressure atmosphere.
Specification:
Type:Wrench chuck type,single water spray 2/4 hole
Air pressure at the back end of HP:206~231 KPa (2.1~2.35 kgf/cm2)
Air pressure at the gauge in the dental unit:240-294 KPa (2.45-3.0 kgf/cm2)
Water pressure:198Kpa (2 kg)
Rotation speed:370,000-420,000 rpm
Head diameter:φ12.5 mm
Head hight:13.14 mm
Bur applicable:φ1.59mm~φ1.6mm×21mm~23mm (diameter×length)
Warranty: One Year! Service: Whole Life!
